SKU: HTDTL19214M115
HTD Timing Belt Pulleys
192-14M-115 HTD PULLEY TL 404
£1,231.67
ex. VAT · £1,478.00 inc. VAT
JS9 Tight Fit Anti-Roll
H7 Precision Transition Fit
ISO 9001 Quality Assured
Technical Specifications
Number of Teeth
192
Pitch (mm)
14
Belt Width (mm)
115
Taper Lock Bushing
4040
Pitch Diameter (mm)
855.62
Outside Diameter (mm)
852.83
Face Width (mm)
133
Min Bore (mm)
40
Max Bore (mm)
100
Weight
95kg
Dimensions (L × W × H)
85.6 × 85.6 × 13.3 cm
Overall envelope
Standards & Fit
JS9
JS9 Keyway
Tight fit anti-roll standard
H7
Precision Transition Fit
Precision bore fit
ISO
ISO 9001:2015
Quality Assured
| Parameter | Value | Notes |
|---|---|---|
| SKU | HTDTL19214M115 | Aroflex part number |
| Number of Teeth | 192 | |
| Pitch (mm) | 14 | |
| Belt Width (mm) | 115 | |
| Taper Lock Bushing | 4040 | |
| Pitch Diameter (mm) | 855.62 | |
| Outside Diameter (mm) | 852.83 | |
| Face Width (mm) | 133 | |
| Min Bore (mm) | 40 | |
| Max Bore (mm) | 100 | |
| Weight | 95 kg | |
| Dimensions | 85.6 × 85.6 × 13.3 cm | Overall envelope |
| Bore Tolerance | H7 | Precision transition fit |
| Material | Steel / Friction disc | Standard construction |
| Certification | ISO 9001:2015 | Quality assured |
192-14M-115 HTD Timing Pulley c/w TL 4040 Taper Lock Bush Bore
The massive 192-14M-115 HTD Timing Pulley stands as the peak configuration in this range, delivering supreme mechanical advantage and extensive speed tuning under heavy industrial conditions. Spreading extreme load dynamics evenly across wide 115mm synchronous timing belts, its 192 deep teeth eliminate tooth fatigue. It features an extra-large hub pre-machined to accommodate a high-torque TL 4040 Taper Lock bush for an incredibly secure, heavy-duty shaft hold.
Product Features & Specifications
- Tooth Configuration: 192 precision-machined heavy-duty teeth.
- Pitch & Belt Width: 14mm heavy pitch profile designed for 115mm wide timing belts.
- Shaft Mounting System: Heavy hub layout fits standard high-torque TL 4040 Taper Lock interlocking bushes.
- Industrial Build Quality: Fabricated using premium-grade, structural Cast Iron (GG).
- Boring & Keying Readiness: Provided in standard raw stock configuration. Tailor the internal bore sizes directly to your shafts via our In-House Machining Services.
