SKU: HTDTL3414M40
HTD Timing Belt Pulleys
34-14M-40 HTD PULLEY TL 2517
£56.39
ex. VAT · £67.67 inc. VAT
JS9 Tight Fit Anti-Roll
H7 Precision Transition Fit
ISO 9001 Quality Assured
Technical Specifications
Number of Teeth
34
Pitch (mm)
14
Belt Width (mm)
40
Taper Lock Bushing
2517
Pitch Diameter (mm)
151.52
Outside Diameter (mm)
148.73
Face Width (mm)
54
Min Bore (mm)
16
Max Bore (mm)
60
Weight
6.9kg
Dimensions (L × W × H)
15.2 × 15.2 × 5.4 cm
Overall envelope
Standards & Fit
JS9
JS9 Keyway
Tight fit anti-roll standard
H7
Precision Transition Fit
Precision bore fit
ISO
ISO 9001:2015
Quality Assured
| Parameter | Value | Notes |
|---|---|---|
| SKU | HTDTL3414M40 | Aroflex part number |
| Number of Teeth | 34 | |
| Pitch (mm) | 14 | |
| Belt Width (mm) | 40 | |
| Taper Lock Bushing | 2517 | |
| Pitch Diameter (mm) | 151.52 | |
| Outside Diameter (mm) | 148.73 | |
| Face Width (mm) | 54 | |
| Min Bore (mm) | 16 | |
| Max Bore (mm) | 60 | |
| Weight | 6.9 kg | |
| Dimensions | 15.2 × 15.2 × 5.4 cm | Overall envelope |
| Bore Tolerance | H7 | Precision transition fit |
| Certification | ISO 9001:2015 | Quality assured |
34-14M-40 HTD Timing Pulley c/w TL 2517 Taper Lock Bush Bore
The 34-14M-40 HTD Timing Pulley transitions to an upgraded, larger hub profile designed to manage increased industrial torque limits. Engineered with 34 heavy teeth at a 14mm pitch, it interfaces tightly with 40mm wide timing belts to suppress operational vibration. This pulley is configured for use with a larger standard TL 2517 Taper Lock bush system.
Product Features & Specifications
- Tooth Configuration: 34 heavy-duty HTD teeth.
- Pitch & Belt Width: Deep 14mm pitch dimensioned for 40mm wide timing belts.
- Shaft Mounting System: Upgraded hub accepts standard TL 2517 Taper Lock interlocking bushes.
- Industrial Build Quality: Built with high-strength Steel (St) or Cast Iron (GG).
- Boring & Keying Readiness: Provided in standard raw stock configuration. Tailor the internal bore sizes directly to your shafts via our In-House Machining Services.
