Workshop Add Bore & Keyway Service

+ £0.00 (£0.00 each)

Order total (product + machining): £32.54

Price varies by bore size and Bore Qty (per machined hub).

Bore size (Hub 1)

Bore size (Hub 2)

Bore Qty (machined items)

Max equals product quantity.

Please Confirm any Additional Machining Details Required (optional)

Keyway size (optional)

Price Breakdown

Up to 25mm (0.984") – (£15)
Up to 40mm (1.575") – (£20)
Up to 60mm (2.362") – (£30)
Over 60mm (2.362"+) – (£45)

Quantity Discount Breakdown

1 to 5 items: No discount
6 to 9 items: 10% off
10 to 19 items: 15% off
20 to 49 items: 20% off
50 to 99 items: 25% off
100+ items: 30% off

SKU: HTDTL448M50 HTD Timing Belt Pulleys

44-8M-50 HTD PULLEY TL 2012

Name: 44-8M-50 HTD Pulley TL 2012 | UK Stock | Arrow Engineering
SKU: HTDTL448M50
Price: 32.54 GBP
Availability: InStock

£32.54

ex. VAT · £39.05 inc. VAT

JS9 Tight Fit Anti-Roll H7 Precision Transition Fit ISO 9001 Quality Assured

In Stock — Dispatches within 24 hours. Bulk orders (10+) available — call for lead time.

Technical Specifications

Number of Teeth

Pitch (mm)

Belt Width (mm)

Taper Lock Bushing

2012

Pitch Diameter (mm)

112.05

Outside Diameter (mm)

110.68

Face Width (mm)

Min Bore (mm)

Max Bore (mm)

Weight

1.98kg

Dimensions (L × W × H)

11.1 × 11.1 × 6 cm

Overall envelope

Standards & Fit

JS9

JS9 Keyway Tight fit anti-roll standard

Precision Transition Fit Precision bore fit

ISO

ISO 9001:2015 Quality Assured

Parameter	Value	Notes
SKU	HTDTL448M50	Aroflex part number
Number of Teeth	44
Pitch (mm)	8
Belt Width (mm)	50
Taper Lock Bushing	2012
Pitch Diameter (mm)	112.05
Outside Diameter (mm)	110.68
Face Width (mm)	60
Min Bore (mm)	14
Max Bore (mm)	50
Weight	1.98 kg
Dimensions	11.1 × 11.1 × 6 cm	Overall envelope
Bore Tolerance	H7	Precision transition fit
Certification	ISO 9001:2015	Quality assured

44-8M-50 HTD Timing Pulley c/w TL 2012 Taper Lock Bush Bore

The 44-8M-50 HTD Timing Pulley provides rugged mechanical performance in mid-to-high power transmission environments. Its wide 44-tooth profile meshes perfectly with 50mm wide synchronous timing belts, maximizing load capacity and eliminating slippage. It is pre-machined to mount firmly to your drive shaft using a standard TL 2012 Taper Lock bush.

Product Features & Specifications

Tooth Configuration: 44 precision-machined HTD teeth.
Pitch & Belt Width: 8mm pitch designed for 50mm timing belts.
Shaft Mounting System: Designed for standard TL 2012 Taper Lock interlocking bushes.
Industrial Build Quality: Fabricated using strong Steel (St) or Cast Iron (GG).
Boring & Keying Readiness: Provided in standard raw stock configuration. Tailor the internal bore sizes directly to your shafts via our In-House Machining Services.
