SKU: HTDTL488M30 HTD Timing Belt Pulleys

48-8M-30 HTD PULLEY TL 2012

Name: 48-8M-30 HTD Pulley TL 2012 | UK Stock | Arrow Engineering
SKU: HTDTL488M30
Price: 27.06 GBP
Availability: InStock

£27.06

ex. VAT · £32.47 inc. VAT

JS9 Tight Fit Anti-Roll H7 Precision Transition Fit ISO 9001 Quality Assured

In Stock — Dispatches within 24 hours. Bulk orders (10+) available — call for lead time.

Technical Specifications

Number of Teeth

Pitch (mm)

Belt Width (mm)

Taper Lock Bushing

2012

Pitch Diameter (mm)

122.23

Outside Diameter (mm)

120.86

Face Width (mm)

Min Bore (mm)

Max Bore (mm)

Weight

2.1kg

Dimensions (L × W × H)

12.1 × 12.1 × 3.8 cm

Overall envelope

Standards & Fit

JS9

JS9 Keyway Tight fit anti-roll standard

Precision Transition Fit Precision bore fit

ISO

ISO 9001:2015 Quality Assured

Parameter	Value	Notes
SKU	HTDTL488M30	Aroflex part number
Number of Teeth	48
Pitch (mm)	8
Belt Width (mm)	30
Taper Lock Bushing	2012
Pitch Diameter (mm)	122.23
Outside Diameter (mm)	120.86
Face Width (mm)	38
Min Bore (mm)	14
Max Bore (mm)	50
Weight	2.1 kg
Dimensions	12.1 × 12.1 × 3.8 cm	Overall envelope
Bore Tolerance	H7	Precision transition fit
Certification	ISO 9001:2015	Quality assured

48-8M-30 HTD Timing Pulley c/w TL 2012 Taper Lock Bush Bore

The 48-8M-30 HTD Timing Pulley offers seamless performance and robust mechanical leverage across industrial drivetrains. Its 8mm pitch curvilinear design ensures high tooth engagement to prevent slippage when paired with 30mm wide synchronous belts. Pre-machined to accept a standard TL 2012 Taper Lock bush, it allows for fast, true clamping onto shafts without the need for additional machining.

Product Features & Specifications

Tooth Configuration: 48 precision-machined HTD teeth.
Pitch & Belt Width: 8mm pitch designed for 30mm timing belts.
Shaft Mounting System: Designed for standard TL 2012 Taper Lock interlocking bushes.
Industrial Build Quality: Crafted from long-lasting Steel (St) or Cast Iron (GG).
Boring & Keying Readiness: Provided in standard raw stock configuration. Tailor the internal bore sizes directly to your shafts via our In-House Machining Services.
