SKU: SS-UC204
UC Series Inserts
SS-UC204 Stainless Steel Insert 1020-20
£8.56
ex. VAT · £10.27 inc. VAT
JS9 Tight Fit Anti-Roll
H7 Precision Transition Fit
ISO 9001 Quality Assured
Technical Specifications
Series
UC Series
Bore Size
20mm
Bore (mm)
20mm
Outside Diameter
47mm
Material
Stainless Steel
Locking Type
Set Screw
Inner Ring
Wide Inner Ring
Housing Compatibility
UC204 family
Application
Food / Washdown / Marine / Corrosive Environments
Bearing Type
Spherical Self-Aligning Insert
Weight
0.16kg
Standards & Fit
JS9
JS9 Keyway
Tight fit anti-roll standard
H7
Precision Transition Fit
Precision bore fit
ISO
ISO 9001:2015
Quality Assured
| Parameter | Value | Notes |
|---|---|---|
| SKU | SS-UC204 | Aroflex part number |
| Series | UC Series | |
| Bore Size | 20mm | |
| Bore (mm) | 20mm | |
| Outside Diameter | 47mm | |
| Material | Stainless Steel | |
| Locking Type | Set Screw | |
| Inner Ring | Wide Inner Ring | |
| Housing Compatibility | UC204 family | |
| Application | Food / Washdown / Marine / Corrosive Environments | |
| Bearing Type | Spherical Self-Aligning Insert | |
| Weight | 0.16 kg | |
| Bore Tolerance | H7 | Precision transition fit |
| Material | Steel / Friction disc | Standard construction |
| Certification | ISO 9001:2015 | Quality assured |
The SS-UC204 is a 20mm bore stainless steel insert bearing from Arrow Engineering’s UC Series, built for environments where standard chrome-steel bearings would corrode. It features a wide inner ring and set screw locking, with a 47mm outside diameter.
The industry-standard insert bearing configuration, offering a wide inner ring for maximum shaft support and reliable set-screw retention suited to bi-directional (reversing) drives.
- Bore: 20mm
- Material: corrosion-resistant stainless steel construction (typically 440C grade for this size range)
- Locking method: set screw locking
- Inner ring type: wide inner ring
- Spherical self-aligning outer race
- Designed as a drop-in replacement insert for UC204 housings, pillow blocks, flange units and take-up units
- Suited to washdown, food & beverage, marine, water treatment and other corrosive or wet-duty applications
Fits standard pillow block, 2-bolt flange, 3-bolt flange, 4-bolt flange and take-up housings sized for the UC204 insert family. Pre-greased and ready to install.
